Contracor High Volume Coalescent Filter

ContracorSKU: CTR-13150100

Capacity: 20 m³/min (CK-50)
Price:
Sale price€464,05 incl. VAT
Stock:
Available for backorder
Shipping in around 1-2 months

Description

The Contracor High Volume Coalescent Filter is a portable, high-performance filter that can remove up to 95% of liquid condensate and dirt particles (up to pm-10) from your compressed air supply. Specially designed for portability and ease of use, this filter is an essential tool for any blasting application. With its powerful filtration capabilities, the Contracor High Volume Coalescent Filter will help keep your equipment running at peak performance by providing clean, dry air.

Coalescence element
The 50/150/250-litre capacity high volume coalescent element removes water from compressed air supply for multiple blast units. As moist air enters the element, it moves up inside the chamber passing through a fine mesh stainless steel filter element that causes the water vapour and oil to coalesce into larger drops that fall to the bottom of the filter. Most particulate material, down to 10 microns, gets trapped in the filter mesh.

Includes
  • 50/150/250 litre volume steel tank
  • Stainless steel coalescent element
  • Safety valve
  • Manual drain valve

Advantages
  • Simple design, special for field use
  • Lower purchase and operating costs than by refrigerated or chemical drying systems
  • Cleaning with water only required for maintenance
Technical data
CK-50 CK-150 CK-250
Maximum working pressure (bar) 12 12 12
Capacity (m³/min) 20 30 45
Vessel volume (litre)
50 150 250
Thread connection, inlet 1½" 2” 2x1½”
Thread connection, outlet 1½" 2” 2x1½”

Documentation

Benutzerhandbuch Download
User Manual Download
